Components
Technical specs
-
Frame
Dusty Stealth Air Carbon, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, Flatmount brake compatible, integrated dropout speed sensor.
Sizes
S: 410mm / M: 450mm / ML: 480mm / L: 510mm / XL: 540mm
-
Fork
Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork
Headset
Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing.
-
Stem
Onoff Semi-Integrated, 31.8mm barbore, rise: -7°, length: S size: 60mm, M size: 70mm, ML size 70mm, L size: 80mm, XL size: 90mm
Handlebar
Onoff S3 GR 16º bar flare. Width sizes: S size: 400mm M size: 420mm ML size: 420mm L size: 440mm XL size: 460mm
-
Grips
Onoff HEX Bartape
Seatpost
Onoff S9 Carbon 15-R, diameter 27.2mm, length: S size: 400mm, M size: 400mm, ML size 400mm, L size: 450m, XL size: 450mm
-
Saddle
Fizik Vento Argo X5 140mm
Front brake
Sram Rival AXS HRD 2 piece caliper, Paceline 160mm Centerlock rotor, steel-backed organic pad
-
Rear brake
Sram Rival AXS HRD, 2 piece caliper, Paceline 160mm Centerlock rotor, steel-backed organic pad
Brake lever
Sram Rival, tooled reach adjust, carbon brake lever
-
Rims
Mavic Allroad S Carbon, UST,42mm height, 25mm internal width, 24 spokes
Spokes
Mavic Steel J Bent spokes
-
Front hub
Mavic, 12x100mm, Centerlock
Rear hub
Mavic infinity hub, 12x142mm, ID360 Ratchet system, Centerlock, XDR Freehub
-
Front tire
Maxxis Reaver 700x50, HYPR-X compound, EXO protection, tubeless ready, 120 TPI, folding bead
Rear tire
Maxxis Reaver 700x50, HYPR-X compound, EXO protection, tubeless ready, 120 TPI, folding bead
-
Crankset
E.13 Piedmont Core E*Spec, S size: 160mm M size: 165mm ML size: 165mm L size: 170mm XL size: 170mm
Rings
Sram X-Sync Eagle 42T, 107BCD, alloy, narrow-wide + E.13 Helix e.spec 107BCD alloy driver
-
Chain
Sram GX Eagle T-Type, 12s, Powerlock
Rear derrailleur
Sram GX Eagle AXS T-Type,12s
-
Shift levers
Sram Rival AXS HRD
Casette
Sram XS-1275, 10-52T, T-Type, 12s
-
Others
Sram AXS Extension Cord, *Optional external battery: TQ 160Wh
Weight
32,2 Lbs
-
Display
TQ HPR Display V04 Color
Motor
TQ HPR-60
-
Battery
TQ HPR Battery V05 580Wh
