Components
Technical specs
-
Frame
Dusty Stealth Air Carbon, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, Flatmount brake compatible, integrated dropout speed sensor.
Sizes
S: 410mm / M: 450mm / ML: 480mm / L: 510mm / XL: 540mm
-
Fork
Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork
Headset
Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing.
-
Stem
Onoff Semi-Integrated, 31.8mm barbore, rise: -7°, length: S size: 60mm, M size: 70mm, ML size 70mm, L size: 80mm, XL size: 90mm
Handlebar
Onoff S3 Urban 1.0 double butted 6061 alloy, rise: 0mm, width: 640mm, 9º backsweep, 0º upsweep, 31.8mm barbore
-
Grips
Ergon GRX black
Seatpost
X-Fusion Manic, diameter 27,2mm,1X Remote lever, All sizes: 310x100mm
-
Saddle
Fizik Vento Argo X5 140mm
Front brake
Shimano CUES U8000, U8010 flatmount caliper, CL-800 ice tech 160mm centerlock rotor, resin pad
-
Rear brake
Shimano CUES U8000, U8010 flatmount caliper, CL-800 ice tech 160mm centerlock rotor, resin pad
Brake lever
Shimano Shimano CUES U8000, tooless reach adjust, aluminium lever.
-
Rims
Mavic Allroad Disc, 25mm internal width, hookless, 28 spokers
Spokes
Mavic Steel J Bent spokes
-
Front hub
Mavic, 12x100mm, Centerlock
Rear hub
Mavic infinity hub, 12x142mm, XD ID360 Ratchet system, Centerlock, MS Freehub
-
Front tire
Maxxis Reaver 700x50, HYPR-X compound, EXO protection, tubeless ready, 120 TPI, folding bead
Rear tire
Maxxis Reaver 700x50, HYPR-X compound, EXO protection, tubeless ready, 120 TPI, folding bead
-
Crankset
E.13 Piedmont Core E*Spec, S size: 160mm M size: 165mm ML size: 165mm L size: 170mm XL size: 170mm
Rings
E.13 Helix Race 42T, 107BCD, Cnc alloy + E.13 Helix e.spec 107BCD alloy driver
-
Chain
Shimano SLX CN-M7100, Quick-Link
Rear derrailleur
Shimano SLX RD-M7100-SGS, 12s
-
Shift levers
Shimano SLX SL-M7100-R, Rapid Fire Plus, 12s
Casette
Shimano SLX CS-M7100-12, Hyperglide+, 10-51, 12s
-
Derailleur hanger
Sram UDH
Others
*Optional external battery: TQ 160Wh
-
Weight
30,9 Lbs
Display
TQ HPR Display V04 Color
-
Motor
TQ HPR-60
Battery
TQ HPR Battery V05 580Wh
