Components
Technical specs
-
Frame
Crafty Stealth Air full Carbon, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
-
Rear shock
Öhlins TTX22M.2 185x55mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, spring preload. Trunnion top mount, 30x8mm bottom bushings
Shock settings
C20 compression, R40 rebound. Spring rate: S size 411 lbs, M size 457 lbs, size ML 502 lbs, L size 548 lbs, XL size 605 lbs
-
Fork
Öhlins RXF 38 M.3 29, 160mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber
Headset
Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
-
Stem
Onoff S9 30mm 0º, Full CNC, 31.8mm barbore
Handlebar
Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
-
Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size
Seatpost
RockShox Reverb Stealth AXS, diameter 31.6mm S size: 398.2x125mm, M size: 448.2x150mm,ML size: 498.2x175mm, L size: 548.2x200mm, XL size:548.2x200mm
-
Saddle
Fizik Vento Argo 00 Carbon 150mm
Front brake
Trickstuff Maxima, 7075 T6 CNC alloy 4 piston caliper, 203mm IS 6 bolts one-piece rotor
-
Rear brake
Trickstuff Maxima, 7075 T6 CNC alloy 4 piston caliper, 203mm IS 6 bolts one-piece rotor
Brake lever
Trickstuff Maxima, 7075 T6 CNC alloy, lever pivot bearings, tools-free reach adjust, Kevlar hose
-
Rims
DT Swiss HXC1200 Carbon Spline 29, 30mm internal width, hookless, tubeless ready, 28 spokes
Spokes
DT complite® Hybrid t-head
-
Front hub
DT 180, Boost 15x110mm, IS 6 bolts
Rear hub
DT 180, Boost 12x148mm, Ratchet EXP OS 42 system, IS 6 bolts, XD freehub
-
Front tire
Maxxis Minion DHF 29x2.5, tubeless ready, 3C Maxx Grip, EXO+ Protection, 600TPI, folding bead
Rear tire
Maxxis Minion DHR II 29x2.5 tubeless ready, 3C Maxx Terra, EXO+ Protection, 60TPI, folding bead
-
Crankset
E.13 Helix Race Carbon E*Spec Plus, All sizes: 160mm
Rings
Sram XX Eagle 34T T-Type, direct mount, steel, CL55
-
Chain
Sram XX Eagle T-Type, 12s, Powerlock
Front derrailleur
Sram XX Eagle AXS, T-Type, 12s
-
Rear derrailleur
Sram Eagle AXS Pod Rocker, 12s
Casette
Sram XS-1295, 10-52T, T-Type, 12s
-
Display
Kiox 400 / Bosch Mini Remote
Motor
Bosch Performance Line CX-R(25Km/h) SMART SYSTEM (BDU386Y)
-
Battery
Bosch Powertube 800Wh
