Frame
e-Gravel Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor.
Sizes
S: 440mm / M: 460mm / L: 500mm / XL: 530mm
-
Fork
RockShox Rudy Ultimate, 40mm travel, 12x100mm maxle stealth, 45mm offset
Headset
OnOff e-gravel tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
-
Stem
OnOff e-gravel 6061 T6 Alloy, 31.8mm barbore, rise: -7º, length: S size: 60mm, M size: 70mm L size: 80mm, XL size: 90mm
Handlebar
OnOff gravel 16º bar flare. Width sizes S size: 440mm M size: 440mm L size: 460mm XL size: 460mm
-
Grips
Barium gravel dark grey
Seatpost
RockShox Reverb XPLR AXS 75mm wireless 27.2X400mm dropper post
-
Saddle
FIZIK Terra Argo X7 150mm
Front brake
SRAM Force Etap AXS 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
-
Rear brake
Sram Force Etap AXS, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
Brake lever
Sram Force, contact point adjustment, tooled reach adjust, plastic shift lever, LFRT brake lever
-
Rims
Mavic Allroad Pro Carbon SL Disc, UST, 23mm internal width, hookless, infinity hubs, 24 spokes front, 28 spokers rear
Spokes
Mavic Steel double butted flat spokes
-
Front hub
Mavic, 12x100mm, IS 6 bolts
Rear hub
Mahle X20 Drive Unit, XDR freehub
-
Front tire
Maxxis Rambler 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead
Rear tire
Maxxis Rambler 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead
-
Crankset
SRAM Force 1 Carbon GLS Wide, S: 170mm, M: 172,5mm, L: 172,5mm, XL: 175mm.
Rings
Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide,
-
Bottom bracket
Mahle DUB pressfit, sealed bearings, w/ torque sensor
Chain
Sram NX Eagle, 12s, Powerlock
-
Rear derrailleur
Sram X01 Eagle AXS, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
Shift levers
Sram Force Etap AXS 12s, X-Actuation 1:1, single click
-
Casette
Sram XG-1275, 10-52T, 12s
Derailleur hanger
Mondraker M076
-
Others
Optional external battery: Mahle e185Wh
Weight
30,6 lb
-
Display
Pulsar One Wireless
Motor
Mahle X20 Drive Unit
-
Battery
Mahle X20 IX350Wh
