Roam solo. Or chase the group ahead on the horizon. Mix it up with your friends or take on your first gravel race. Or simply leave the world behind for the weekend. There’s no wrong way to go, so long as you go!
Riding gravel brings you endless opportunities to experience the world, at the pace and the place that you choose. The new Mondraker Arid is your gateway to the Mondraker gravel scene and the world beyond your doorstep.
Try something new.
ARID S
"The frame shares the same sleek lines as the carbon model, with special details like the seat stays blending seamlessly into the seat tube."
ARID S
"Other things that carry over from the existing carbon Arid include the bike’s longer, slacker geometry, array of mounts across the bike, the unique seatstay ‘window’ design."
Sifft Michael
Good quality Beautiful color
2025 August
Components
Frame
Arid alloy, T47 bottom bracket, tapered head tube, HHG internal cable routing, 12x142mm rear axle, 1X drivetrain design, Flatmount brake compatible.
Sizes
S: 410mm / M: 450mm / ML: 480mm / L: 510mm / XL: 540mm
Fork
Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork
Headset
Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing.
Stem
Onoff S3 6061 T6 Alloy, 31.8mm barbore, rise: -7º, length: S size: 60mm, M size: 70mm, ML size 70mm, L size: 80mm, XL size: 90mm
Handlebar
OnOff S3 GR 16º bar flare. Width sizes S size: 440mm M size: 440mm ML size: 460mm L size: 460mm XL size: 460mm
Grips
OnOff HEX Bartape
Seatpost
Onoff S3 0-R, diameter 27.2mm, length 400mm
Saddle
FIZIK Terra Argo X5 140mm
Front brake
Shimano GRX RX-610, RX-400 caliper, CL-800 ice tech 160mm centerlock rotor, resin pad
Rear brake
Shimano GRX RX-610, RX-400 caliper, CL-800 ice tech 160mm centerlock rotor, resin pad
Brake lever
Shimano GRX RX-610, contact point adjustment, tooled reach adjust, aluminium lever.
Rims
Mavic Allroad Disc, UST, 25mm internal width, hookless, infinity hubs, 24 spokes front, 28 spokers rear
Spokes
Mavic Steel double butted flat spokes
Front hub
Mavic, 12x100mm, IS 6 bolts
Rear hub
Mavic infinity hub, 12x142mm, XD ID360 Ratchet system, IS 6 bolts, MS Freehub
Front tire
Maxxis Reaver 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead
Rear tire
Maxxis Reaver 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead
Crankset
Shimano GRX RX-610, S size: 170mm M size: 170mm ML size: 172,5mm L size: 172,5mm XL size: 175mm, CL 49,7
Rings
Shimano 40T, direct mount, steel
Bottom bracket
Token T47 BSA sealed bearings, 85,5mm
Chain
Shimano SLX M7100, Quick link
Rear derrailleur
Shimano GRX RX-822-GS, 12s
Shift levers
Shimano GRX RX-610 dual control, alloy lever
Casette
Shimano SLX M7100, hiperglide+,10-45, 12s
Derailleur hanger
Sram UDH
Weight
24,0 lbs
This size table is only an estimation, the optimum frame size depends on your personal preference and riding style
|
Frame size
|
S | M | M/L | L | XL | |
|---|---|---|---|---|---|---|
| A | Seattube length | 410 mm 16.14" | 450 mm 17.72" | 480 mm 18.90" | 510 mm 20.08" | 540 mm 21.26" |
| B | Toptube length | 520 mm 20.47" | 550 mm 21.65" | 580 mm 22.83" | 600 mm 23.62" | 630 mm 24.80" |
| C | Bottom bracket drop | -75 | -75 | -75 | -75 | -75 |
| D | Bottom bracket height | 269 mm 10.59" | 269 mm 10.59" | 269 mm 10.59" | 269 mm 10.59" | 269 mm 10.59" |
| E | Chainstay length | 425 mm 16.73" | 425 mm 16.73" | 425 mm 16.73" | 425 mm 16.73" | 425 mm 16.73" |
| F | Seat tube angle | 73° | 73° | 73° | 73° | 73° |
| G | Effective seattube angle | 74° | 74° | 74° | 74° | 74° |
| H | Headtube angle | 70° | 70° | 70° | 70° | 70° |
| I | Fork Offset | 45 mm 1.77" | 45 mm 1.77" | 45 mm 1.77" | 45 mm 1.77" | 45 mm 1.77" |
| J | Wheelbase | 1003 mm 39.49" | 1035 mm 40.75" | 1067 mm 42.01" | 1089 mm 42.87" | 1121 mm 44.13" |
| K | Headtube length | 100 mm 3.94" | 125 mm 4.92" | 145 mm 5.71" | 175 mm 6.89" | 200 mm 7.87" |
| L | Reach | 363 mm 14.29" | 386 mm 15.20" | 411 mm 16.18" | 423 mm 16.65" | 446 mm 17.56" |
| M | Stack | 548 mm 21.57" | 572 mm 22.52" | 591 mm 23.27" | 619 mm 24.37" | 642 mm 25.28" |
| N | Stem Length | 60 mm 2.36" | 70 mm 2.76" | 70 mm 2.76" | 80 mm 3.15" | 90 mm 3.54" |
| O | Fork Height | 420 mm 16.54" | 420 mm 16.54" | 420 mm 16.54" | 420 mm 16.54" | 420 mm 16.54" |
frame
Arid alloy, T47 bottom bracket, tapered head tube, HHG internal cable routing, 12x142mm rear axle, 1X drivetrain design, Flatmount brake compatible.
sizes
S: 410mm / M: 450mm / ML: 480mm / L: 510mm / XL: 540mm
fork
Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork
headset
Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing.
stem
Onoff S3 6061 T6 Alloy, 31.8mm barbore, rise: -7º, length: S size: 60mm, M size: 70mm, ML size 70mm, L size: 80mm, XL size: 90mm
handlebar
OnOff S3 GR 16º bar flare. Width sizes S size: 440mm M size: 440mm ML size: 460mm L size: 460mm XL size: 460mm
grips
OnOff HEX Bartape
seatpost
Onoff S3 0-R, diameter 27.2mm, length 400mm
saddle
FIZIK Terra Argo X5 140mm
front brake
Shimano GRX RX-610, RX-400 caliper, CL-800 ice tech 160mm centerlock rotor, resin pad
rear brake
Shimano GRX RX-610, RX-400 caliper, CL-800 ice tech 160mm centerlock rotor, resin pad
brake lever
Shimano GRX RX-610, contact point adjustment, tooled reach adjust, aluminium lever.
rims
Mavic Allroad Disc, UST, 25mm internal width, hookless, infinity hubs, 24 spokes front, 28 spokers rear
spokes
Mavic Steel double butted flat spokes
front hub
Mavic, 12x100mm, IS 6 bolts
rear hub
Mavic infinity hub, 12x142mm, XD ID360 Ratchet system, IS 6 bolts, MS Freehub
front tire
Maxxis Reaver 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead
rear tire
Maxxis Reaver 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead
crankset
Shimano GRX RX-610, S size: 170mm M size: 170mm ML size: 172,5mm L size: 172,5mm XL size: 175mm, CL 49,7
rings
Shimano 40T, direct mount, steel
bottom bracket
Token T47 BSA sealed bearings, 85,5mm
chain
Shimano SLX M7100, Quick link
rear derrailleur
Shimano GRX RX-822-GS, 12s
shift levers
Shimano GRX RX-610 dual control, alloy lever
casette
Shimano SLX M7100, hiperglide+,10-45, 12s
derailleur hanger
Sram UDH
weight
24,0 lbs
This size table is only an estimation, the optimum frame size depends on your personal preference and riding style
