Components
Technical specs
-
Frame
Grommy 16 6061 Alloy Stealth Evo, HHG internal cable routing, Resin footrest, Resin motor cover, Resin chain protector, Post mount disc brake mount.
Sizes
One size: 250mm
-
Fork
MDK 16 Kid, Rigid alloy Stealth stanchions, Post Mount disc brake mount
Headset
FPD CHEX-1089, Internal ZS, 44/50 upper and lower cup
-
Stem
MDK, 6061 melt forged alloy, 25.4mm barbore, rise: 0º, length: 30mm
Handlebar
MDK 1.0, 6061 alloy, rise: 25mm, width: 500mm, 9º backsweep, 5º upsweep, 25.4mm barbore
-
Grips
Kids
Seatpost
Pivotal
-
Saddle
MDK Kids series
Rear brake
Tektro MD-510 Mechanical hydraulic, flat mount caliper, 140mm IS 6 bolts rotor
-
Brake lever
Tektro JL-350RS kids specific alloy 4 fingers
Rims
MDK-Push 16, alloy 21mm internal width, 28 spokes
-
Spokes
CN round stainless steel black
Front hub
KT K88F 9x100mm cup&cone ball bearings 6 bolts
-
Rear hub
KT TV-3R 9x110mm cup&cone ball bearings
Front tire
Vee Tire Crown Gem 16x2.25 27TPI Wired Bead
-
Rear tire
Vee Tire Crown Gem 16x2.25 27TPI Wired Bead
Rings
10T, steel
-
Chain
KMC Z33 Half Link, 1 speed.
Casette
DNP freewheel 16T
-
Display
MDK LED Throttle 3speed position, battery range.
Motor
MDK brushless 250w Output
-
Battery
MDK 4Ah 80Wh
